Exclusive Tiles

Technical Specification

CHARACTERISTIC	EURO STANDARDS ISO 13006/EN 176 GROUP Bla	OUR MEAN VALUE	TEST METHOD
DIMENSION & SURFACE QUALITY
Deviation in length	± 0.6%	± 0.1%	ISO 10545-2
Deviation in thickness	± 5.0%	± 1.0%	ISO 10545-2
Straightness in side	± 0.5%	± 0.1%	ISO 10545-2
Rectangularity	± 0.6%	± 0.1%	ISO 10545-2
Surface flatness	± 0.5%	± 0.1%	ISO 10545-2
Surface Gidline	Min. 95% of tiles shall be free from visible defect	PASS the Test	ISO 10545-2
PHYSICAL & THERMAL PROPERTIES
Water absorption	< 0.5%	< 0.20%	ISO 10545-3
Mohs Hardness	Min 0.5%	Min.5	EN-101
Modules of rupture	>35 N/mm2	40 N/mm2	ISO 10545-4
Breaking strength	>1300 N N	>1800 N	ISO 10545-4
Crazing Resistance	No Damage	No Damage	ISO 10545-11
Thermal Shock Resistance	No Damage	No Damage	ISO 10545-9
Moisture Expansion	No Damage	No Damage	ISO 10545-10
Resistance to Surface Abrasion	Abrasion class shall be specified by the manufacturer	PEI IV & V	ISO 10545-7
CHEMICAL PROPERTIES
Chemical resistance	No damage	No damage	ISO-10545-13
Colour resistance	No Damage	No Damage	ISO-10545-16
Stain resistance	Resistant	Resistant	Resistant

CHARACTERISTIC	EURO STANDARDS ISO 13006/EN 176 GROUP Bla	OUR MEAN VALUE
DIMENSION & SURFACE QUALITY
Dimension	± 0.5%	± 0.4%
Deviation in thickness	± 0.6% mm	± 0.5% mm
Straightness in side	± 0.3%	± 0.2%
Rectangularity	± 0.5%	± 0.3%
Surface flatness	± 0.5%	± 0.5%
Surface Quality	Min. 95%	Min. 96%
PHYSICAL PROPERTIES
Water absorption	>10%	13.5
Bending Strength	150 kg/Cm2	200 – 250 Kg/Cm2
Scratch hardness(Mohs)	Min 3	Min 3
Crazing	I Cycle	No Crazing at 5 Cycle
CHEMICAL PROPERTIES
Staining Resistance	Min Class 2	Resistance to all Acids and Alkalies & Household chemical, Except Hydrofluoric Acid.
Household Chemical	Min Class B	Resistance to all Acids and Alkalies & Household chemical, Except Hydrofluoric Acid.
THERMAL PROPERTIES
Thermal Shock	Resistant to 10 Cycle	CONFORMS
Thermal Expansion	Max-9E-06	CONFORMS
